Manfrotto
Manfrotto 502AH Head/055XPRO3 Tripod Kit Rental
- Up to 19.8 lb Payload
- Tripod Up to 66.9" Tall
- EasyLink 3/8" Connector

The Manfrotto 502AH Head/055XPRO3 Tripod Kit combines the MVH502AH fluid head with the 055XPRO3 aluminum tripod. The fluid head features a variable fluid drag system on both its pan and tilt axes, a pre-set spring-loaded counterbalance of 8.8 lbs, continuously adjustable tilt drag, a tilt range of +90 to -80°, and a versatile camera plate with a 3.27" range. The head comes with a pan bar and an EasyLink 3/8" connector to attach accessories such as video monitors or LEDs. The tripod legs can hold up to 19.8 lbs of gear and can get as low as just 3.5" above the ground thanks to a wide leg range and a center column that can be rapidly set vertically or horizontally. Like the head, there is an EasyLink 3/8" connector for mounting your own brackets, arms, and stud-based clamps. The bubble level rotates freely around the flat head mount so that you can see it no matter how your system is attached. All of these small design touches result in a versatile tool suitable for projects of all genres.
Type: 75mm Flat base Head & Legs with 3/8"-16 Mount Points
Load Capacity: 19.8 lbs (Legs), 15.4 lbs (Head)
Minimum Height: 3.5"
Maximum Height: 66.9"
Folded Length: 24"
Sections: 3
Material: Aluminum
Weight: 5.5 lbs (Legs), 3.73 lbs (Head)
